5 Ton and 10 Ton 6M Electric Chain Hoist for Sale to Philippines

Technical specifications and dimensions of 5tn and 10tn electric chain hoist to Philippines:

Number			Electric chain hoist
Capacity		t	5	10
Lifting height		m	6
Speed	Travel speed	m/min	11
	Lifting speed		2.7
Working level		/	A3
Chain diameter		mm	11.2
Chain quantity		/	2	4
Power supply		Fase/V/Hz	3/440/60
Lifting power		KW	3.0
Traveling power			0.75
Total power			3.75
Total weight		Kg	245	473
Recommended track width		mm	100-178	150-220
Control method		/	Control colgante
Motor rotation speed		r/min	1440
Ambient temperature		℃	-20 ~+40

Design drawing of 5 Tons and 10 Tons electric chain hoist to Philippines:

5 Tons and 10 Tons electric chain hoist configurations of parts to Philippines:

Motor housing		It is made of the light weight aluminum alloy housing. It is light but tough. The cooling fin ensures fast heat dissipation rate up to 40% and continuous service. The closed integral structure is applicable to places such as chemical plants and plate factories.
Motor		It is specially designed for electric chain hoist. It is maintenance free. Insulation class F. IP54 protection level.
Gearbox		The gearbox Forged medium carbon steel, good toughness, impact resistance and strong load capacity, made of generating method, gear grinding processing, high precision.
Electric Trolley		The alloy frame with electric motor and wheels have high abrasion resistance. It is compact and easy to install.
Chain		The chain adopts imported ultra-trafficable aluminum alloy chain. It can use in the environment such as rain, sea water and chemical.
Chain bag		Nylon material. It keeps the chain lifted and prevents tangling.
Hook		It is hot forging with perfect strength which is hard to break. The operation safety of the bottom hook is guaranteed by its 360 degree rotation and safety flap.
Electricidads		CHINT is the most famous brand in China.
Limiter		The limiter is installed where the weight is lifted at intervals to stop the motor.
Pendant control		Safe and reliable



5 Ton and 10 Ton electric chain hoist:

 Key Features to Look for in a 5 Ton and 10Ton Electric Chain Hoist:

1. Hoisting speed: choose a crane with high hoisting speed to increase working efficiency and reduce waiting time.
2. Durability and Material: Make sure the crane is made of high quality material with good durability and corrosion resistance for long time use.
3. Safety features: Check whether the crane is equipped with safety features such as overload protection, emergency stop button and limit switch to ensure safe operation.
4. Maintenance convenience: Choosing equipment that is easy to maintain and service can reduce downtime and improve overall efficiency.
5. Adaptability: Ensure that the crane can adapt to different working environments and load requirements, such as high temperature, humidity and other conditions.
6. Power Requirements: Confirm that the crane's power requirements match the site conditions to avoid reduced efficiency due to power problems.
7. Installation and mobility: Consider the ease of installation and mobility of the crane, especially in cases where frequent changes of workplace are required.
8. BRAND REPUTATION AND AFTER-SALES SERVICE: Choose a well-known brand to ensure good after-sales service and technical support.

Maintenance Tips for Longevity for Your 5 Ton and 10 Ton Electric Chain Hoist:

• Chain: Apply appropriate chain lubricant regularly to prevent rust and ensure smooth operation.
• Moving Parts: Lubricate gears, bearings, and other moving parts as specified in the manufacturer's guidelines.
• Wiring Check: Inspect electrical cables and connections for wear or damage. Replace any frayed wires immediately.
• Control System: Ensure the control pendant and buttons are functioning correctly and free from debris.
• Tensioning: Ensure the chain is properly tensioned to avoid excessive wear or slippage.
• Periodic Testing: Conduct load tests at regular intervals to ensure the hoist can safely handle its rated capacity.
• Check Safety Devices: Ensure that safety features like limit switches and overload protection systems are operational.
• Moisture Protection: If operating in a humid environment, consider using a protective cover when not in use.

Cost vs. Quality: Finding the Right Balance in Electric Chain Hoist

• Initial Cost: Determine your budget while considering both purchase price and long-term costs like maintenance and repairs.
• Operational Costs: Evaluate energy efficiency and potential downtime costs.
• Established Brands: Opt for brands with a proven track record of reliability and customer satisfaction, even if they come at a higher price.
• Construction: Look for hoists made from durable materials, such as high-grade steel, which can withstand heavy use and adverse conditions.
• Corrosion Resistance: Consider hoists with protective coatings if operating in harsh environments.
• Built-in Safety Mechanisms: Invest in hoists with features like overload protection, emergency stop buttons, and limit switches, which can prevent accidents.
• Lifting Speed and Duty Cycle: Higher quality hoists often provide better performance and longer duty cycles, enhancing productivity.
• Versatility: Consider hoists that can accommodate various lifting tasks without needing additional equipment.
• Maintenance Needs: Higher-quality hoists may have lower maintenance requirements and longer lifespans, offsetting initial costs.

In balancing cost and quality, it’s important to assess your specific operational needs and long-term usage. Investing in a slightly more expensive hoist with better quality and safety features can ultimately save you money and improve efficiency over time.

5 Ton and 10 Ton electric chain hoist processing:

5 Ton and 10Ton electric chain hoist processing involves several steps that require precision, attention to detail and quality control to manufacture reliable, high quality lifting equipment.

Design - Material selection - Cutting and forming - Assembly - Wiring and electrical components - Testing.
