Lifting Capacity: 2 ton
Span: 10 m
Lifting Height: 10 m
Working Class: A3
Note: We can design and manufacture the crane according your requirments and working conditions.
Item | Portable Gantry Crane | |
Capacity | ton | 2 |
Lifting height | m | 10 |
Span | 10 | |
Power Supply | V/HZ/Phase | 440/60/3 |
Control | / | Pendant control |
Lifting speed | m/min | 6.6 |
Hoist moving speed | 11 | |
Crane moving speed | 8 | |
Hoist power | kw | 3.0 |
Hoist moving power | 0.4 | |
Crane moving power | 0.75*2 | |
Total power | 4.9 | |
Chain diameter | mm | 10.0 |
Working class | / | A3 |
Protection class | / | IP54 |
Insulation grade | / | F |
Total weight | ton | 6.2 |
Ambient temperature | / | -20℃ ~ +40℃ |
Structure | Convenient transportation and simple installation. Antioxidante | |
Wheels | Electric wheels for stronger support and smooth movement. | |
Hoist | 2tn Electric Chain Hoist IP54 protection class | |
Hook | Hot forged. Safe and durable. | |
Motor | Specially designed for electric hoist. Maintenance free. Insulation class F. Protection level IP54. | |
Trolley | Alloy frame with electric motor and wheels have high abrasion resistance. It is compact and easy to install. |
|
Chain | The chain will adopt imported ultra-heat-treated ultra-tractable aluminum alloy chain. It can be safely used in energy environments such as rain, sea water and chemicals. |
|
Overload limiter | The limiter is installed where the weight is lifted at intervals to stop the motor. | |
Electrics | CHINT is the most famous brand in China. | |
Control method | Safe and reliable Protection Class IP65 |
Investing in a 2 ton portable gantry crane with an electric hoist can greatly enhance operational efficiency, safety, and versatility in various industrial settings. Whether for construction, manufacturing, or maintenance tasks, this portable gantry crane proves to be a powerful solution for lifting heavy loads with ease.
When working with heavy loads, safety is paramount. A 2 ton portable gantry crane equipped with an electric chain hoist incorporates several safety features to protect users and ensure efficient operation. Here are some key safety features:
When selecting a 2 ton portable gantry crane, it's essential to consider various factors to ensure you choose the right equipment for your needs. This guide will help you navigate the key aspects to consider.
