Lifting Capacity: 1.5 ton
Span: m
Lifting Height: 26 m
Working Class:
Note: We can design and manufacture the crane according your requirments and working conditions.
Motor shell | It is made of light aluminum alloy shell, light but hard. The cooling fin is especially designed to ensure quick heat dissipation with the rate up to 40% and continuous service. The integral enclosed structure is applicable to places like chemical plant and electroplate factory. | |
Motor | Special designed for the electric chain hoist. Maintenance free. Insulation grade F. Protection class IP54. Side magnetic braking system inside | |
Gearbox | Forged medium carbon steel, good toughness, strong impact resistance& bearing capacity, made by generating method, gear grinding processing, high precision degree | |
Electric Trolley | High strength low alloy steel structure, with electric motor and high-wearing feature wheels, compact and easy to install | |
Chain | The chain shall adopt the imported ultra-heat treatable aluminum alloy chain. It can be safety used in power environments such as rain, sea water and chemicals | |
Chain bag | High wear resistance nylon material, store the lifting chain and prevent the chain from getting entangled with the main card or the chain when the chain is free to slide | |
Hook | It is hot forging with perfect strength that is hard to break. The operation safety of the lower hook is ensured by its 360 degrees rotation and safety flap | |
Electrics | CHINT brand, China famous brand, Inverse phase sequence protecting device | |
Limiter switch | The limit switch device is installed where the weight is lifted on and off to make the motor to stop automatically so as to prohibit the chains from exceeding for safety | |
Remote control | Radio frequency control Safe and reliable |
Previous:1 Ton 7M Electric Chain Hoist for Sale to Nigeria
Next: Sorry no more
Please leave us the required Crane specification for Quick Quotation.
